The Ultimaker S-line printer has an optimized bed level probing procedure where the printer can calculate the bottom footprint of G-code model and only probe the bed where necessary — only where the printed model will touch the bed. Klipper firmware’s adaptive bed meshing speeds up bed mesh generation (leveling) in a similar way.

Source: Klipper

The Issue

Recently, I found a bug where the Ultimaker S-line firmware will hang and fail to print 3D models with a complex bottom layer or no ;LAYER: comments. When these conditions influenced by the 3D model and exported G-code worsen, the footprint discovery will not finish within a time limit and the Ultimaker printer requires a soft reset.

Source: Ultimaker forum (A similarly cryptic, but not as print-ending error)

What the user sees will be:

1. Ultimaker S-line printer homes the printhead and bed.

2. The bed and nozzles preheat.

3. The bed raises for bed probing using the nozzles.

4. The bed stops moving before touching the probing nozzle. The printer will wait.

5. After a few minutes, the bed Z-axis stepper motor is powered down due to inactivity and the bed may slide down.

6. Eventually the printer will show an error:

An unspecified error has occurred in the motion controller. Restore to default settings.

The printer user interface will show one action available to Reboot. After rebooting and trying to run the print, it’s clear that the same error will occur.

Note: I added AI generated header images to break up the walls of text in this post and keep things interesting for non-technical readers.

Ultimaker S-line Printer Architecture

Ultimaker S-line 3D printers run both a linux kernel and Marlin firmware. The touch screen user interface and networking is handled by the Linux “management” side and the printer motion controller code is based on Marlin. The last public documentation on Ultimaker’s architecture is the helpful Inside the Ultimaker 3 - Day 4 - Electronics post in 2016 on the Ultimaker forum.

Source: Ultimaker forum

This is in contrast to the Ultimaker Original+ and 2 that use an embedded Atmega2560 microcontroller running Marlin to control all aspects of the printer.

Source: Ultimaker forum

Finding the Cause

Fortunately, the Ultimaker S-line has logging functionality built into Linux management side and a logdump is written to the plugged in USB drive before rebooting.

Filtering the Logs

After opening the compressed logdump, I found dmesg log in the boot.log series of files. The dmesg shows all saved logs up to the last error that triggered the logdump. I was able to located the relevant portions of log that pertained to the last failed print attempt by searching for the filename of the failed print file.

INF - parseHeaderStep:70 - Handling file '/media/usb0/XXX'

Looking further up in the log, the USB flash drive detection event can be found.

The following lines of the log show the printer calibration and preheating status. There may be a couple of lines with “errors” due to lack of internet connectivity or Ultimaker subscription. I’m using an Ultimaker S7 and S5 at school. The first obvious sign of trouble is this line.

WAR - transportLayer:232 - Got error line 1 from printer: Error:SERIAL_INPUT_TIMEOUT: No commands received over time. Safety shutdown

followed by the next lines in between the AUTO_LEVEL_BED abort messages

ERR - controller:956 - Halting ALL procedures
ERR - applicationLayer:324 - Marlin error: SYSTEM HALT!

At this point, the printer asks you to reboot it.

There’s not much to go off of besides SERIAL_INPUT_TIMEOUT which looks like a constant value.

Surface level symptoms

I have contributed to the Marlin 3D printer firmware project before and Ultimaker was a main contributor to Marlin firmware in the past.

I’m not sure how actively Ultimaker contributes to the open source version of Marlin today but it’s nice to see that Marlin lives on in their 3D printer line up.

Ultimaker has released the source code of their version of Marlin called UltimakerMarlin. There is a branch in the UltimakerMarlin Github repo named S-line with the last update in February 2021. I searched the code for SERIAL_INPUT_TIMEOUT and the resulting code shows that check_serial_input_timeout() checks if the time since the last serial data input has been over MONITOR_SERIAL_INPUT_TIMEOUT seconds, stop() is called with the reason STOP_REASON_SERIAL_INPUT_TIMEOUT. stop() then sends the serial message through SERIAL_ECHOLNPGM which the Marlin developers recognize.

MONITOR_SERIAL_INPUT_TIMEOUT is defined as 5 minutes in the most recent released code.

Ultimaker has added a message protocol in UltimakerMarlin to communicate with the Linux side of the printer with messages formatted a standard way.

Based on what we’ve found so far, it’s highly likely UltimakerMarlin — which runs the motion controller side of the printer — stopped receiving data from the Linux “management/UI” side for at least 5 minutes.

Comparison of Print Logs

I narrowed down which logged abnormalities were likely to have caused the Linux management side to stop sending messages to the motion controller by comparing the logs of a successful print with a failed print.

Remember that the printer dumps all recent saved logs?

Another user of the printer had successfully finished a print and I found the logs from a past print job further up in the boot.log file.

Note: Ultimaker logs do not appear to show any private data. The model filename and optimized probing points are the only identifying info. The software states at the time of errors seem to be sent to Sentry, crash analytics service, if the printer is connected to the internet. Unlike other 3D printer companies, Ultimaker appears to be transparent about their logging and not obsfucating logs.

I viewed both logs from the failed and successful prints side by side and first scrolled to the chronological location where the SERIAL_INPUT_TIMEOUT was found. The error shows up 3 lines after the following unique BedLevelProbingProcedure step is logged in both the failed and successful prints.

INF - procedure:489 - BedLevelProbingProcedure(key='AUTO_LEVEL_BED', outcome=None) transitioning from 'ProbeSingleNozzleOffsetStep(key='PROBE_Z_OFFSET_FOR_VALIDATION_0')' >  'GotoPositionStep(key='GO_TO_SAFE_TRAVEL_HEIGHT_STEP')'
INF - printerService:195 - Procedure next step: AUTO_LEVEL_BED: GO TO SAFE TRAVEL HEIGHT STEP
INF - gotoPositionStep:86 - Moving to: x:None y:None z:20 e:None speed:None, relative:False, immediate:True

The bed probing procedure matches what I observed in real life. The printer homes the printhead and bed, preheats the bed and nozzles, and raises the bed along the Z axis towards the nozzle which is at the 0 Z position.

Note: For those unfamiliar with the Ultimaker cartesian printer design, the higher Z position is at the bottom of the printer because the bed lowers away from the printhead which is fixed at the top of the printer case as the object is printed and gains height.

After the error message is received by the Ultimaker Linux management system, the next queued bed level procedure is started before management system starts halting procedures.

Successful and Failed Print file comparison

The only obvious difference between the successful and failed print files was the size. I had previously successfully printed models sliced in both Cura and PrusaSlicer so the slicer was unlikely to be the cause. Both slicers output standard G-code printing commands.

The failed print file was larger in size. Maybe the Ultimaker system could not handle a larger print file?

Locating Other Clues

The logdump is the only user visible record of what events led up to the motion controller crash and forced printer reboot. We need to use intuition and find more patterns in the logs we have.

The filesize of the printing G-code file is the only factor that increases processing time of the Ultimaker. The maximum axes, number of extruders, materials, and, bed probe area have set upper bounds that do not increase with printing G-code size.

The file size shouldn’t matter since G-code is newline delimited and the memory efficient way to process the G-code is to read and execute a single line at a time.

Was the Ultimaker preprocessing the file for a purpose and this could bog down the Linux management system?

INF - gCodeFootprintFinder:69 - PARSED LAYER: ['LAYER', '0']
INF - gCodeFootprintFinder:69 - PARSED LAYER: ['LAYER', '1']

The above events are logged in the successful print.

Wait. The Ultimaker is parsing layer 0 and layer 1 as part of the bed probe optimization. By determining the minimum footprint of the printed object that touches the bed, bed probing could cover only the printed area which can save time.

A footprint completion event for the successful print:

INF - footprintProbeGridComputer:51 - Parsed the GCode to find the footprint coordinates in 1.2092304229736328 seconds

A footprint completion event for the failed print:

INF - footprintProbeGridComputer:51 - Parsed the GCode to find the footprint coordinates in 696.0990624427795 seconds

696 seconds is a long time. It’s longer than the motion controller timeout MONITOR_SERIAL_INPUT_TIMEOUT which is 300 seconds (5 minutes).

While the footprint finder runs, a couple of synchronization warnings are logged.

WAR - timer:257 - Timer(PrintProcedureMetadataHelper.onChanged.timer) ran more than a second out of sync! (-1.116920)

The footprint finder takes too long and blocks the Linux management controller from sending new messages to the Marlin motion controller.

Eventually the footprint calculation will finish and the printer will move to the next queued step in the AUTO_LEVEL_BED procedure. After the printer has processed the next queued step, it will get around to processing the motion controller SERIAL_INPUT_TIMEOUT error that occurs because the footprint calculation blocks message sending for more than 5 minutes.

Firmware Attempts to End Processing Early

After SERIAL_INPUT_TIMEOUT is received, the Ultimaker management system logs an attempt to end the footprint calculation as STOP_FOOTPRINT_COMPUTER and probe the entire bed in lieu of probing a smaller area to fit the footprint.

INF - procedure:489 - BedLevelProbingProcedure(key='AUTO_LEVEL_BED', outcome=OutcomeBase.Aborted) transitioning from 'SwitchActiveHotendStep(key='SWITCH_HOTEND_FOR_VALIDATION_0')' >  'CallbackStep(key='STOP_FOOTPRINT_COMPUTER')'
INF - printerService:195 - Procedure next step: AUTO_LEVEL_BED: STOP_FOOTPRINT_COMPUTER
INF - footprintProbeGridComputer:73 - Active thread was still running, setting all cells to probe
INF - gCodeFootprintFinder:31 - Received call to stop footprint computation

STOP_FOOTPRINT_COMPUTER is sent as soon as the Marlin motion controller error is received so the decision to abort the footprint calculation is sent upon a motion controller error and STOP_FOOTPRINT_COMPUTER is not premptively invoked before the 5 minute timeout window.

After a motion controller error, the only UI action available is to reboot which is a soft reset that does not require physically resetting the printer power switch.

I assume that the single threaded nature of Python locks execution during the footprint calcuation and blocks the message system also running in Python from talking to the motion controller.

Going Deeper

We could end here and call it a day but let’s see if we can figure out where the bug resides in the Ultimaker system. Maybe we will find a workaround in the current firmware and possible patches! If you want to see the G-code workaround now, feel free to scroll to the end of this post.

Ultimaker has helpfully included line numbers in logged events. So all we need to initially do is follow the footprints.

Starting with the first footprint event

INF - bedLevelProbingProcedure:306 - Using footprint probing

Line 306 of bedLevelProbingProcedure.py is in the abbreviated function prepareFootprintProbing() below.

  def prepareFootprintProbing(self) -> None:
    try:
      print_procedure = cast(PrintProcedure, self.__controller.getProcedure("PRINT"))
      gcode_metadata = print_procedure.getGcodeMetaData()
    except ValueError:
      gcode_metadata = None

    if gcode_metadata is not None and gcode_metadata.getGroupCount() <= 1:
      log.info("Using footprint probing") # <--- Line 306
      self.__footprint_probe_grid_computer = FootprintProbeGridComputer(self.__controller)
      self.__footprint_probe_grid_computer.computeFootprintProbeGrid(probe_grid=self.__probe_grid)

prepareFootprintProbing() starts the footprint discovery by calling computeFootprintProbeGrid(probe_grid: ProbeGrid).

computeFootprintProbeGrid(probe_grid: ProbeGrid) first calls findFootprintCoordinates(stream: IO[bytes]) -> List[List[float]] to get all movement command coordinates (G0 and G1 only, no G2/G3 arc movements).

def findFootprintCoordinates(self, stream: IO[bytes]) -> List[List[float]]:
  self.__reset()

  for line in stream:
    self.__process(line)
    if self.__should_stop:
      break

  return self.__coordinates

The file stream is read line by line until ;LAYER:N is found with a number N greater than 0. During this loop to read the stream, a variable __should_stop is checked to see if the footprint coordinate finding should stop. __should_stop is set to True when a layer marker with a layer number greater than 0 is found or when the stop() function is called from finalizeComputation() which in turn is called when STOP_FOOTPRINT_COMPUTER message is received or footprint grid is needed on demand.

if self.__layer > 0:
  self.__should_stop = True
  return  # Not processing this layer

def stop(self) -> None:
  log.info("Received call to stop footprint computation")
  self.__should_stop = True

After all the coordinates touched before layer > 0 are returned, computeFootprintProbeGrid(probe_grid: ProbeGrid) calls ConvexHull.find(cls, points: List[List[float]]) -> List[Vector2] to return a trimmed list of the convex hull coordinates (the outside coordinates ring of the all found coordinates) and updateWithBoundedSubSet(boundary_vectors: List[Vector2]) (I’ll call this the Grid Bounded SubSet) to figure out the actual grid cells to probe.

Long Running Algorithms and Thread Execution

Unlike findFootprintCoordinates(stream: IO[bytes]) which ends early when STOP_FOOTPRINT_COMPUTER message is received, the ConvexHull and updateWithBoundedSubSet(boundary_vectors: List[Vector2]) algorithms do not check for early termination.

Source: Wikipedia - Maonus

The Convex Hull algorithm used is Quickhull and has a worst case run time of O(N^2) where N is the number of coordinates before layer 1. Although the most likely worst run time is O(N) if the printed model has a circular base.

I didn’t look at Grid Bounded SubSet algorithm too closely but it seems to have a similar worst case runtime of O(N^2).

Now that we are looking at the code, the log message we looked at previously that output the footprint coordinate G-code parsing time does not represent the total processing time to find a probing grid. The log entry with the parsing time is logged is after all coordinates in the file have been found in findFootprintCoordinates(stream: IO[bytes]) and before the Convex Hull and probing grid cells are calculated.

Now it makes sense why the log event for STOP_FOOTPRINT_COMPUTER was found AFTER the log events for footprint coordinate G-code parsing time and motion and motion controller error.

INF - printerService:195 - Procedure next step: AUTO_LEVEL_BED: STOP_FOOTPRINT_COMPUTER
INF - footprintProbeGridComputer:73 - Active thread was still running, setting all cells to probe

def finalizeComputation(self) -> None:
  if self._thread is not None:
    if self._thread.is_alive():
      log.info("Active thread was still running, setting all cells to probe")
      self.__footprint_finder.stop()
      self._thread.join()
      self.__probe_grid.setCellsToProbe(1)
      self.__probe_grid.updateQuickGridIndices(dimension=self.__probing_config.dimension)

The Convex Hull or Grid Bounded SubSet algorithm is running from when the parsing time message is logged to whenever each algorithm fully completes.

The Python thread does not join in time and updateQuickGridIndices(dimension: Dimension) never runs (we know this because the new quick probe indices are not logged like they are in the successful print log).

After this attempt to early abort the footprint finder is unsuccessful the Ultimaker printer would normally wait for the footprint finder to end naturally.

ERR - applicationLayer:324 - Marlin error: SYSTEM HALT!
ERR - controller:956 - Halting ALL procedures

Due to the Marlin motion controller error, it determines an unsafe condition may have occured (e.g. motion controller keeps the heater on) so some more error messages are logged indicating halting more parts of the system. Then Ultimaker requires a reboot.

Possible Patches

The Linux management controller could keep track of the time elapsed since the last message to the motion controller. It can also send STOP_FOOTPRINT_COMPUTER and fall back to a full bed probe before the 5 minute timeout window expires if the communication system cannot be refactored around Python threading and blocking issues.

A reference to the __should_stop variable can be passed to the Convex Hull and Grid Bounded SubSet algorithms. Each loop of the algorithm then checks the referenced variable to see if it should end early.

Workarounds

If we need to print with the current Ultimaker S-line firmware and we have a condition where we cannot change the 3D model or add proper ;LAYER indicators, we need to supply the footprint finder with a simplified set of coordinates before ending it with our own ;LAYER:1.

Ultimaker footprint finder G-code matching

# Only handle G0, G1 commands with X,Y movement
keys = gcode_line.getParameterDictionaryKeys()
if "G" in keys and gcode_line.getValue("G", return_type=str) in self.__allowed_commands:
  if "X" in keys or "Y" in keys:
    self.__coordinates.append(self.__currentPositionToCoordinates())

In general, the workaround requirements are:

1. Include G0 travel commands to the 4 corners of the bed (extruder movement is not needed) in our start G-code. Although these G-code will be found ahead of time by the footprint finder’s lookahead, these G-code should come AFTER any homing code to avoid possible collisions.

2. Include a ;LAYER:1 after these G0 travel commands so that the footprint finder ends due to encountering a layer marker for a layer > 0.

Start G-code workaround example for PrusaSlicer:

G280 S1 ; Ultimaker 3 and S-line home and bed probe without prime blob

; Stop bed probe area computation early and use the entire bed.
G0 X{print_bed_min[0]} Y{print_bed_max[1]}
G0 X{print_bed_min[0]} Y{print_bed_min[1]}
G0 X{print_bed_max[0]} Y{print_bed_min[1]}
G0 X{print_bed_max[0]} Y{print_bed_max[1]}
;LAYER:1

; Put the rest of your start G-code here

Note: We still need to show a minimum of the actual print bottom footprint coordinates to the footprint finder before it stops or else the footprint finder will return a single prefilled point which is the default nozzle probe position in the back right of the bed and the printer will warn about an unbalanced model.

After I posted this on the Ultimaker forum, Robinmdh from Team Ultimaker mentioned that adding ;PRINT.GROUPS:2 to the header will also skip adaptive bed probing. Setting 2 print groups will indicate additional first layers for other objects printed further in the G-code.

Bonus Bug!

I found another bug in the Ultimaker G-code header parser in the process of creating a PrusaSlicer profile for the Ultimaker S-line printers. The Ultimaker Griffin G-code header must be replicated in order for the Ultimaker S-line printers to recognize G-code files as valid.

When the parser validates a GENERATOR.VERSION composed only of numbers and periods without a third version component (usually the patch or bugfix number), the UI shows a ER999 - An unspecified error has occurred screen that forces a reboot. The G-code header values and results:

GENERATOR.VERSION:2.7.1 <- good
GENERATOR.VERSION:2.7   <- bad
GENERATOR.VERSION:A.A   <- good

ERR - procedureStep:113 - Exception caught from step: CHECK
Traceback (most recent call last):
  File "/usr/share/griffin/griffin/printer/procedures/procedureStep.py", line 89, in _run
    outcome = self.run()
  File "/usr/share/griffin/griffin/printer/procedures/pre_and_post_print/runChecksBeforePrint.py", line 77, in run
    results = gcode_metadata.getValidator(c).validate()  # type: List[GCodeMetaDataContainerValidator.ValidationResult]
  File "/usr/share/griffin/griffin/datatypes/gcodeMetaDataContainerValidator.py", line 44, in validate
    self.__validateCuraVersion()
  File "/usr/share/griffin/griffin/datatypes/gcodeMetaDataContainerValidator.py", line 93, in __validateCuraVersion
    version: str = self.__header_container.getGeneratorVersion()
  File "/usr/share/griffin/griffin/datatypes/gcodeMetaDataContainer.py", line 45, in getGeneratorVersion
    return self.__metadata[self.__metadata_prefix + "generator"].get("version", "0.0.0").lower()
AttributeError: 'float' object has no attribute 'lower'
CRI - marvinService:127 - Added Fault: <Fault: level=2 code=102 message='Unhandled exception from ProcedureStep CHECK' data='dbus.Dictionary({}, signature=dbus.Signature('sv'))'>

The G-code header validator attempts to get the lowercase version of the generator version string in the metadata dictionary. The validator expects all the header values be stored as string when the header is parsed and the float data type has no lower() function.

For some reason the version is stored as a float instead of a string in the failing case. I thought the version may be handled special but all I found was a general insertKeyValuePair() function that handles all the header data insertion.

The header parser inserts a key value pair into the metadata dictionary in a recursive manner that I simplified below. There is no explicit type conversion or casting.

 metadata[key[0]] = value

When the original value consists of digits and at most 1 decimal, value’s type is implicitly converted to a float. When non-digits or multiple decimals are present in value, it is stored as a string.

When the version is later retrieved from the dictionary, it is expected to be a string and an error occurs otherwise due to the next validation steps expecting a string and not a float.

Another header parsing function for the build_plate type also calls the lower() method which has the same implicit type issue.

Each header parsing function for a specific field returns the expected type so it’s clear that some of the header values are meant to be saved as numeric data types and not as strings.

A header parsing solution could be checking the type of the stored metadata value and doing an explicit type conversion before doing any processing of the value.

Conclusion

We found at least 2 edge cases that force a soft reset on the Ultimaker S-line 3D printers. The root causes were identified and successful workarounds found.

01MAR24 - I notified Ultimaker of the Bed Leveling Footprint Finder and Gcode header bugs.

05MAR24 - Ultimaker acknowledged the bug and based on a comment on the community forum, it seems that the bug will be fixed in the next firmware release with no date given.

Musings While We’re At It

Ultimaker makes a streamlined 3D printer line of dual color 3D FDM printers and in recent years, they have pivoted away from the hobbyist audience to institutional customers. This seems to happen to many 3D printer companies when a “time is more valuable than money” customer base is found.

Ultimaker printers are well built (my UMO+ and UM2+ printers are still going strong!) and have above average reliability. This is partly due to overengineering as well as conservative performance estimates and limited features compared to new 3D printers from Prusa and Bambu. Without incorporating new hardware features that benefit the common user, a company can only float on support contracts for so long until other “newly established” competitors come for a piece of the pie (e.g. Bambu X1E, Prusa Pro).

I don’t even want to think about the rebrand of Makerbot printers to appear as if the Method printer is an adjacent, nonoverlapping product line on par with or remotely related to the Ultimaker S-line printer. Currently, there is no Ultimaker S-line vs Method 3D printer specification comparison on the Ultimaker website post-merger with Makerbot. For 3D printer users who are familiar with the printing capabilities of Method and Ultimaker printers, it feels like there was an extra stock of Method printers to offload after the merger.

Ok, that’s enough criticism. I may be a bit too harsh there but it had to be said from the perspective of a non-institutional 3D printer user, software developer, and Ultimaker fan.

Ultimaker is killing it in the slicing software aspect as the lead developer of the open source Cura slicer software. Cura has consistently incorporated new slicer innovations at the front of the pack competing slicers. Notable examples that come to mind are Ironing, Tree Supports, and (more recently) Organic Tree Supports.

Cura may look the most refined out of all the slicers and that often gives the impression that it’s a walled garden with no customizability. The opposite is actually the case here. Cura exposes more print settings than others which empowers the user to get a better print!

Psst, you can download and print my 3D topo maps here

Similar to iOS and Android, CuraEngine and Slic3r based slicers (PrusaSlicer and Bambu Studio) have kept abreast with each other in feature parity over the years. The formerly formidable commercial competitor, Simplify3D, is basically dead at this point. The open source nature of both projects allows developers from both projects to freely borrow good ideas from the other project so the 3D printing community grows as a whole.

I look forward to seeing Ultimaker’s innovations that improve the 3D printing industry and community in the future!

Anson Liu

By

What type of content do you plan to share with your subscribers?

Enter your email address to subscribe. *
